SC1670 Silicon Carbide Grinding Media

Silicon Carbide Grinding Media Properties

Silicon Carbide Ceramic Grinding Ball

Compound Formula	SiC
Molecular Weight	40.1
Appearance	Black
Melting Point	2,730° C (4,946° F) (decomposes)
Density	3.0 to 3.2 g/cm3
Electrical Resistivity	1 to 4 10x Ω-m
Poisson’s Ratio	0.15 to 0.21
Specific Heat	670 to 1180 J/kg-K

Download Silicon Carbide SDS

Silicon Carbide Grinding Media Description

Silicon Carbide Grinding Media is a very high-cost grinding media that are used for milling same materials (silicon carbide ball to mill silicon carbide materials) to avoid contamination. It has good wear resistance and high density. Sizes ranging from 5mm, 10mm, 12mm, 15mm and 20mm sizes. Also, customized size is available.

Silicon Carbide Grinding Media Specifications

Type	Unit	Data
Volume density	g/cm3	3.08-3.16
SiC	%	>99.2
Vicker shardness HV	Kg/mm2	>2550
Compressive strength	MPa	>2500
Bending strength	MPa	400-490
Elastic Modulus	GPa	>410
Thermal Conductivity	W/m.k	100-120
Thermal expansion coefficient	i/℃	4.0
Porosity	%	<0>
Operating temperature	℃	1900

Silicon Carbide Grinding Media Applications

Silicon carbide grinding media is widely used in different types of ceramics, enamel, glass, and thick and hard materials in chemical plants for fine grinding and segmentation.

Packing Service

ACM’s silicon carbide ceramic grinding media is carefully handled to minimize damage during storage and transportation and to preserve the quality of our products in their original condition.
