AC2323 Alumina Foam Filter, Aluminum Oxide Foam Filter

Catalog No.	AC2323
Size	7", 9", 12", 15", 17", 20", 23"
Compositions	85% Al2O3
Working Temperature	≤1200°C
Pores Per Inch	10-60

Alumina Foam Filter Description

Alumina Foam Filter is mainly for filtration of aluminum and aluminum alloys in foundries and cast houses. With its excellent resistance to attack and corrosion from molten aluminum, it can effectively remove inclusions, reduce trapped gas and provides laminar flow, and then the filtered metal is significantly cleaner. Cleaner metal results in higher-quality castings, less scrap, and fewer inclusion defects, all of which contribute to bottom-line profit.

Alumina Foam Filter Specifications

Physical Properties

Working Temperature	≤1200°C
Porosity	80~90%
Compression Strength (Room Temperature)	≥1.0Mpa
Volume Density	≤0.5g/cm3
Thermal Shock Resistance	800°C—room temperature 5 times
Application	non-ferrous and alumina alloys, high temperature gas filter, chemical fillings and catalysis carrier etc.

Chemical Composition

Al2O3	SiC	SiO2	ZrO2	Others
85 % approx	—	6% approx	—	9% approx

Alumina Foam Filter Applications

Alumina foam filters can be used in the following applications:
– Molten aluminum
– Copper-based alloys
– Ferrous metals including grey
– Ductile and steel alloy
