| Compound Formula | BN |
| Molecular Weight | 24.82 |
| Appearance | White |
| Melting Point | 2973 °C |
| Density | 2.1 g/cm3 (h-BN); 3.45 g/cm3 (c-BN) |
| Solubility in H2O | Insoluble |
| Refractive Index | 1.8 (h-BN); 2.1 (c-BN) |
| Electrical Resistivity | 13 to 15 10x Ω-m |
Boron nitride, or BN, is a chemical compound with equal numbers of boron and nitrogen atoms. The hexagonal form (HBN) corresponding to graphite is the softest and most stable form among BN polymorphs, and is therefore used as lubricant and an additive to cosmetic products. The cubic (CBN) variety analogous to diamond has high hardness which is inferior only to diamond. The rare wurtzite BN (WBN) modification is similar to lonsdaleite, and it may even be harder than CBN.
– Boron Nitride parts for ion injection equipment
– Electric insulators in vacuum system
– Spacers for glass melting
– Feed through for high voltage equipment
– Boron Nitride components for PVD, MOCVD, MBE system.
| Material | Description | Availability |
| BN99 | Hot pressed at high temperature (1900℃). Excellent corrosion resistance and thermal conductivity. Limited wear resistance Self-bonded and high purity(>99%) |
Machinable Blanks Finished Parts |
| BNBO | General purpose material Bonded by boric oxide |
Finished Parts |
| BNCB | Calcium borate bonded boron nitride Enhanced moisture resistance |
Finished Parts |
| BN60 | BN 60%, SiO2 40% | Finished Parts |
| BN40 | BN 40%, SiO2 60% | Finished Parts |
| ZSBN | BN-45%, Zr2O3 45% | Finished Parts |
Specifications of BN99 and ZSBN for your reference!
ACM’s Boron Nitride Custom Machined Parts are carefully handled to minimize damage during storage and transportation and to preserve the quality of our products in their original condition.
