| Compound Formula | BN |
| Molecular Weight | 24.82 |
| Appearance | White |
| Melting Point | 2973 °C |
| Density | 2.1 g/cm3 (h-BN); 3.45 g/cm3 (c-BN) |
| Solubility in H2O | Insoluble |
| Refractive Index | 1.8 (h-BN); 2.1 (c-BN) |
| Electrical Resistivity | 13 to 15 10x Ω-m |
Boron Nitride, also known as BN, Hexagonal boron nitride (H-BN) and hot pressed boron nitride, is a good self-lubricate ceramic that can withstand high temperature and maintain its lubricating capability in high vacuum environment. SAM Boron Nitride crucibles are made from hot pressed boron nitride blank. Hexagonal boron nitride (H-BN) behaves similar with graphite mechanically, but offers excellent electrical resistance.
| Material | Description | Availability |
| BN99 | Hot pressed at high temperature (1900℃). Excellent corrosion resistance and thermal conductivity. Limited wear resistance Self-bonded and high purity(>99%) |
Machinable Blanks Finished Parts |
| BNBO | General purpose material Bonded by boric oxide |
Finished Parts |
| BNCB | Calcium borate bonded boron nitride Enhanced moisture resistance |
Finished Parts |
| BN60 | BN 60%, SiO2 40% | Finished Parts |
| BN40 | BN 40%, SiO2 60% | Finished Parts |
| ZSBN | BN-45%, Zr2O3 45% | Finished Parts |
Specifications of BN99 and ZSBN for your reference!
Boron Nitride ceramic from China Special Ceramic Parts, Inc. can withstand high temperature in high vacuum environment, plus it has excellent corrosion resistance and electrical resistance. Thus, Boron Nitride ceramic product is an ideal choice in a wide range of industries, such as:
– Crucibles for crystal growth
– Break rings for horizontal casting machine
– Insulators for high temperature furnace
– Electric insulators in vacuum system
– Feed through for high voltage equipment
ACM’s Hot Pressed Boron Nitride Crucible is carefully handled to minimize damage during storage and transportation and to preserve the quality of our products in their original condition.
