Cerium Hexaboride Powder Properties

Cerium Boride Powder

Compound Formula	CeB6
Molecular Weight	204.98
Appearance	Purple
Melting Point	2552°C
Density	4.80-4.87 g/cm3
Solubility in water	insoluble
Crystal structure	Cubic

Cerium Hexaboride Powder Description

Cerium Boride, also called Cerium Hexaboride or CeB6, is a refractory ceramic material. The principal use of cerium hexaboride is a coating of hot cathodes, or hot cathodes made of cerium hexaboride crystals. It usually operates at temperature of 1450 °C.

Borides are hard, high-melting materials with metal-like conductivity, and they are stable to nonoxidizing acids but break down in strong oxidizing agents and strong alkalis. Borides are used in semiconductors, superconductors, diamagnetic, paramagnetic, ferromagnetic, anti-ferromagnetic, turbine blades, and rocket nozzles.

Material Data for LaB₆ and CeB₆

Parameter	Units	LaB₆	CeB₆
Stoichiometry	N/A	~6
Metal Impurities	ppm by wt.	<30>
Density	g/cm³	4.72	4.80
Coefficient of Thermal Expansion	α x 106	5.6	6.2
Electrical Resistivity	uΩ-cm	~50	~65
Effective Work Function (100) at 1800 K	eV	2.70	2.65
Spectral Emissivity at 0.65 microns	N/A	0.765	0.779
Evaporation rate at 1800 K (UHV)	g/cm²/s	2.2 x 10^-9	1.6 x 10^-9
Orientation limit for specific orientation	degrees	<2>
Pyrolitic block mount resistance @ 1800 K	Ohms	1.45

Cerium Hexaboride Powder Applications

-Thermionic emission (cathode)
-Plasma source for plasma enhanced coating(PECVD)
-Vacuum electron beam welding machine
-Electron beam surface reforming device
-Electron beam lithography device
-Transmission electron microscope
-Scanning electron microscope
-Surface analysis device
-Radio therapy devices

Packing Service

ACM’s Cerium Hexaboride Powder is carefully handled to minimize damage during storage and transportation and to preserve the quality of our products in their original condition.
